Pump, 4" Submersible 3-Phase (Multiquip ST4125D)
Specs (Specifications may change due to continuous product development)
Multiquip ST4125D Specifications | | Unit Specifications | | Impeller Type | Cast Ductile Iron | | Impeller Disc Size | 4" (100 mm) | | Maximum Head | 125 ft. (38 m) | | Water Capacity | 464 gpm (1756 lpm) | | Maximum Solids | - - | | Electrical Specifications | | Power | 10 HP (7.5 kW) | | Voltage, Phase | 230/460V 3Ø | | Starting Amp | 149 (230V); 75 (460V0 | | Running Amperage | 27 (230V); 14 (460V) | | Cable Length | 50' (15.2 m) | | Dimensions & Weights | | Pump Diameter | 14.2" (361 mm) | | Overall Height | 32.7" (831 mm) | | Operating Weight | 330 lbs.. (150 kg) |
|
