Barreto 916H/918H Handlebar Assembly - 1

  • Hover over the part on the breakdown below and click to see details
  • Click the red arrows to navigate to the next area of the machine
  • All parts shown are listed below the photo
  • Clicking on the part will take you to the part





00614

00614 CONTROL BLOCK ASSEMBLY Barreto 916H-918H Tiller

Your Price: $387.55

Click For Price and Specs

03009-R1

03009-R1 HOUR METER WITH FLASH ALERT Barreto 916H-918H Tiller

Click For Price and Specs

03029

03029 LEVER ASSEMBLY COMPLETE Barreto 916H-918H Tiller

Your Price: $55.98

Click For Price and Specs

03032-01

03032-01 GRIP 1 X 5 Barreto 916H-918H Tiller

Your Price: $6.33

Click For Price and Specs

03501

03501 BUSHING IGUS MFI-0810-08 Barreto 916H-918H Tiller

Your Price: $17.40

Click For Price and Specs

05059

05059 HH CAP SCREW 3/8-16 NC X 1 G5 ZINC Barreto 916H-918H Tiller

Your Price: $1.94

Click For Price and Specs

05067

05067 HH CAP SCREW 1/2-13 NC X 1 G5 ZINC Barreto 916H-918H Tiller

Your Price: $2.86

Click For Price and Specs

05069

05069 WHIZ-LOCK 1/4-20 X 5/8 Barreto 916H-918H Tiller

Your Price: $1.94

Click For Price and Specs

05078

05078 WASHER 1/4 USS ZINC Barreto 916H-918H Tiller

Your Price: $1.46

Click For Price and Specs

05081

05081 WASHER 1/4 SAE ZINC Barreto 916H-918H Tiller

Your Price: $1.46

Click For Price and Specs

05093

05093 HH CAP SCREW 1/2-13 NC X 3 G5 ZINC Barreto 916H-918H Tiller

Your Price: $14.01

Click For Price and Specs

05096

05096 NUT NYLOCK 1/4-20 NC ZINC Barreto 916H-918H Tiller

Your Price: $1.46

Click For Price and Specs

05098

05098 NUT NYLOCK 1/2-13 NC ZINC Barreto 916H-918H Tiller

Your Price: $1.94

Click For Price and Specs

05101

05101 WASHER 3/8 SAE ZINC Barreto 916H-918H Tiller

Your Price: $1.46

Click For Price and Specs

05102

05102 WASHER 1/2 SAE ZINC HARDENED Barreto 916H-918H Tiller

Your Price: $1.94

Click For Price and Specs

05123

05123 HH CAP SCREW 1/4-20 NC X 2-1/2 G5 ZINC Barreto 916H-918H Tiller

Your Price: $2.86

Click For Price and Specs

05169

05169 WHIZ-LOCK 5/16-18 X 1/2 Barreto 916H-918H Tiller

Your Price: $7.05

Click For Price and Specs

05222

05222 COTTER PIN 1/8 X 3/4 Barreto 916H-918H Tiller

Your Price: $1.21

Click For Price and Specs

05273

05273 NUT NYLOCK 5/16-18 NC ZINC Barreto 916H-918H Tiller

Your Price: $1.46

Click For Price and Specs

05568

05568 HH CAP SCREW 5/16-18 NC X 2-1/2 G5 ZINC Barreto 916H-918H Tiller

Your Price: $1.94

Click For Price and Specs

05611

05611 SH CAP SCREW 1/4-20 NC X 3/4 ZINC Barreto 916H-918H Tiller

Your Price: $2.00

Click For Price and Specs

06420

06420 ROCKER SWITCH IGNITION OFF/ON Barreto 916H-918H Tiller

Your Price: $19.28

Click For Price and Specs

10100

10100 BUSHING IGUS RFI-0810-06 Barreto 916H-918H Tiller

Your Price: $23.13

Click For Price and Specs

10212

10212 (10498) BUSHING IGUS MFI-2024-12 Barreto 916H-918H Tiller

Your Price: $17.35

Click For Price and Specs

10615

10615 WASHER 5/16 USS ZINC Barreto 916H-918H Tiller

Your Price: $1.28

Click For Price and Specs

11027

11027 SHAFT WASHER Barreto 916H-918H Tiller

Your Price: $8.22

Click For Price and Specs

16503

16503 HANDLEBAR PIVOT Barreto 916H-918H Tiller

Click For Price and Specs

16504

16504 PIVOT MOUNT Barreto 916H-918H Tiller

Your Price: $103.83

Click For Price and Specs

16505

16505 LOCK HANDLE Barreto 916H-918H Tiller

Click For Price and Specs

16506

16506 SPRING CENTURY 320 Barreto 916H-918H Tiller

Your Price: $54.06

Click For Price and Specs

16510

16510 CABLE ACTUATOR Barreto 916H-918H Tiller

Your Price: $55.50

Click For Price and Specs

16511

16511 ADJUSTMENT BAR SHAFT Barreto 916H-918H Tiller

Your Price: $78.86

Click For Price and Specs

16512

16512 ADJUSTMENT COG Barreto 916H-918H Tiller

Your Price: $72.92

Click For Price and Specs

16513

16513 SPRING CENTURY 11141 Barreto 916H-918H Tiller

Click For Price and Specs

16536

16536 WHEEL RANGE Barreto 916H-918H Tiller

Click For Price and Specs

16542

16542 HOSE KEEPER-918 Barreto 916H-918H Tiller

Click For Price and Specs

16544

16544 SLIDE PIN Barreto 916H-918H Tiller

Your Price: $12.99

Click For Price and Specs

16545

16545 HANDLE BARS R1 Barreto 916H-918H Tiller

Your Price: $373.67

Click For Price and Specs
