Generac Magnum MLT3060M / MLT3060K / MLT3080M / MLT3080K Trailer Assembly

  • Hover over the parts to see the part number
  • Click the red arrows to navigate to the next area of the machine
  • All parts shown are listed below the photo
  • Clicking on the part will take you to the part



Trailer Assembly
Coupler Spacer Ball Coupler Lunette Ring Weldment Lunette Ring Weldment Combo Hitch Safety Chain Channel Coupler Removable Tongue Weldment Retaining Ring Top Wind Jack Jack Adapter Weldment Jack Assembly Jack Assembly Jack Adapter Weldment Top Wind Jack Retaining Ring Outrigger Weldment Spare Tire Holder Plunger Kit Chassis Weldment Retaining Ring Side Wind Jack Jack Adapter Weldment Jack Assembly Jack Mounting Bracket Jack Assembly Jack Adapter Weldment Top Wind Jack Retaining Ring Outrigger Weldment Screw Shackle Bracket Plate Nut Lug Nut Wheel Wheel Bearing Cap Nut Tie-Plate Spring U-bolt Wheel Stud Roller bearing Axle Hub Seal Spindle Nut Axle Assembly

11100

11100 Axle, 2200 lb. Generac Magnum Light Tower

Your Price: $309.99

Click For Price and Specs

11201

11201 Axis Axle U-bolt 2200 lb. Generac Magnum Light Tower

Your Price: $9.33

Click For Price and Specs

11202

11202 Axis Axle tie-plate 2200 lb. Generac Magnum Light Tower

Your Price: $14.73

Click For Price and Specs

11203

11203 Axis Axle nut (U bolt) 2200 lb. Generac Magnum Light Tower

Your Price: $3.29

Click For Price and Specs

11206

11206 Axle Hub w/ Studs and Outer Races Generac Magnum Light Tower

Your Price: $55.78

Click For Price and Specs

11207

11207 Axis Axle wheel stud .500-20 Generac Magnum Light Tower

Your Price: $6.99

Click For Price and Specs

11221

11221 Bracket, jack mounting - 1.25 deep Generac Magnum Light Tower

Your Price: $20.38

Click For Price and Specs

11511

11511 Axis Axle roller bearing Generac Magnum Light Tower

Your Price: $22.66

Click For Price and Specs

11681

11681 Jack, side wind - 2000 lb. Generac Magnum Light Tower

Your Price: $89.23

Click For Price and Specs

11682

11682 Jack, top wind - 2000 lb. Generac Magnum Light Tower

Your Price: $83.98

Click For Price and Specs

11965Z

11965Z Weldment, jack adapter Generac Magnum Light Tower

Your Price: $26.98

Click For Price and Specs

12155B

12155B Spacer, coupler - black Generac Magnum Light Tower

Your Price: $46.78

Click For Price and Specs

12235B

12235B Weldment, spare tire holder Generac Magnum Light Tower

Your Price: $294.99

Click For Price and Specs

12308

12308 Spindle nut Generac Magnum Light Tower

Your Price: $3.29

Click For Price and Specs

12420B

12420B Weldment, removable tongue Generac Magnum Light Tower

Your Price: $161.99

Click For Price and Specs

12431Z

12431Z Weldment, outrigger Generac Magnum Light Tower

Your Price: $114.43

Click For Price and Specs

12460

12460 Axis axle, wheel bearing cap Generac Magnum Light Tower

Your Price: $12.39

Click For Price and Specs

13000

13000 Axis axle seal - 2200 lb. Generac Magnum Light Tower

Your Price: $7.53

Click For Price and Specs

13003B

13003B Coupler, 2.00 ball/3/00 channel Generac Magnum Light Tower

Your Price: $214.99

Click For Price and Specs

13050

13050 (11978) Jack Assembly 2000 lb. Side Wind Generac Magnum Light Tower

Your Price: $91.33

Click For Price and Specs

13051

13051 (23254) Jack Assembly 2000# Top Wind Generac Magnum Light Tower

Your Price: $81.88

Click For Price and Specs

13819B

13819B Weldment, LT chassis Generac Magnum Light Tower

Your Price: $1,029.00

Click For Price and Specs

14324

14324 Kit, plunger Generac Magnum Light Tower

Your Price: $26.38

Click For Price and Specs

14326

14326 Ring, retaining Generac Magnum Light Tower

Your Price: $3.29

Click For Price and Specs

15976

15976 Wheel, 13" Generac Magnum Light Tower

Your Price: $204.99

Click For Price and Specs

16679

16679 Spring - 25 in. 2200 lb. Generac Magnum Light Tower

Your Price: $79.78

Click For Price and Specs

16741ZC

16741ZC Weldment, combo hitch - 2.50 tongue Generac Magnum Light Tower

Your Price: $115.48

Click For Price and Specs

16830

16830 Coupler, 2.00 ball/2.50 channel Generac Magnum Light Tower

Your Price: $38.98

Click For Price and Specs

16835B

16835B Weldment, lunette ring - 3.00 ID Generac Magnum Light Tower

Your Price: $148.99

Click For Price and Specs

16999B

16999B Weldment, lunette ring - 2.50 ID Generac Magnum Light Tower

Your Price: $93.43

Click For Price and Specs

19637

19637 Plate, shackle bracket Generac Magnum Light Tower

Your Price: $3.29

Click For Price and Specs

23367

23367 Chain, safety - 7,800 lbs. rated Generac Magnum Light Tower

Your Price: $28.78

Click For Price and Specs

60096

60096 Nut, .500-20 wheel lug Generac Magnum Light Tower

Your Price: $3.29

Click For Price and Specs

60503

60503 Screw, .562-18 hx shackle Generac Magnum Light Tower

Your Price: $3.29

Click For Price and Specs

60504

60504 Nut, .562-18 hx shackle lock Generac Magnum Light Tower

Your Price: $3.29

Click For Price and Specs
